Parameter Units Min Typ Max
Frequency Range GHz 10.6 10.8
Tuning Voltage Limits V +3 +7
Power Output at +25°C (50ohm load) dBm +7 +10
Modulation Sensitivity MHz/V 175 350
Frequency Drift vs. Temperature MHz 125
Frequency Pulling (12dB Return Loss) MHz 20
Frequency Pushing MHz/V 2.5
SSB Phase Noise at 10kHz offset dBc/Hz -50
SSB Phase Noise at 100kHz offset dBc/Hz -77
Second Harmonic dBc -12
Modulation Bandwidth MHz 10
Spurious dBc -60
Bias Voltage V 14.85 15 15.15
Bias Current mA 100 120
Operating Temperature °C 0 +85 |
